Johnson Controls M9208-GGA-3 Electric Actuator, 70 in-lb. Running Torque, -40 to 140 Degree F
Product details
| Management number | 213599146 | Release Date | 2026/04/12 | List Price | $140.55 | Model Number | 213599146 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The M9208-xxx-x Series Electric Spring-Return Actuators provide control of dampers in HVAC systems. All actuators in this series provide 70 lb·in (8 N·m) rated torque. A mechanical spring-return system provides rated torque with and without power applied to the actuator. These actuators are configured for direct mounting and do not require a damper linkage. Actuators can be mounted directly to a damper shaft from 5/16 to 5/8 in. (8 to 16 mm) diameter with a universal clamp. For shafts up to 3/4 in. (19 mm) diameter, use the accessory Large Shaft Coupler Kit M9208-600. An accessory crank arm and remote mounting kit are available for applications where the actuator cannot be direct coupled to the damper shaft. Optional line voltage auxiliary switches indicate an end-stop position or perform switching functions within the selected rotation range.
- 70 lb·in (8 N·m) rated torque
- Direct-coupled design
- Reversible mounting
- Electronic stall detection
- Double-insulated construction
| Item Weight | 2.77 pounds |
|---|---|
| Manufacturer | Johnson Controls Inc |
| Item model number | M9208-GGA-3 |
| Product Dimensions | 6 x 12 x 6 inches |
